## Smooth 1D Colors #6

Now that is much better. The only thing that has changed is the scale on the palette. The colors palette is “slowed” by a factor of 50. In my program, this value is called color entropy. Previous image = 0.16, this one = 0.0032.

Notice that the color bands are gone. The colors are still set by the integer valued escape count. The only change is the change in the palette scale factor.

Discrete color values do not matter in deep zooms.

The observation should be intuitive, we have large numbers for the escape count, then apply a very small scale factor to the palette. So each step if very small. The difference between two adjacent colors is imperceptible.

Suppose color 0 is black and color 1 is white, your monitor can display only 256 shades of gray between these two color. Put into the 0-1 range, your monitor has discrete shades at each 0.0039 step. In today’s picture, the fractal calculation is scaling the palette by a factor of 0.0032. Each “fractal step” is finer than the “display step”.

This series of post is leading up to different kinds of smooth colors. The conclusion, “do deep zooms” is not the final answer, just the first observation on the journey.

## Smooth 1D Colors #5

Obviously, this image is not meant to be visually appealing. It is an example of what goes wrong. Fractal artists see these things quite often, and they are quickly remove from the hard drive and computer memory. Thus propagating the illusion that all fractals are pretty.

So what went wrong, and why? This image is deep zoom into an interesting area of the Mandelbrot set called a Misiurewicz point. The problem is the palette is set to the same scale as in the previous image. You can see the same color steps if you look at the few areas that are not just random colors.

If you have a map, this Misiurewicz point is near -0.2073 + 0.6947i. The horizontal (x) range of the image is +/- .0004.

What is most significant is that the escape count ranges from 75 to 1921, with average value of 500 (and for the statistic nerd, standard deviation of 22.17). These are much larger numbers, distributed over a larger range than in the previous image. So most pixels get assigned a (fapp) random color with no apparent correlation to adjacent pixels.

In the previous image the escape count range was 2 to 481, with average 4, and sd=2.18. Many fewer colors, and smaller variations.

## Smooth 1D Colors #4

The sharp contrast in the color bands works best for two complementary colors. Black and white is probably the best choice. Today’s example feature a more gradual color change. From white, through some shades of brown and then shades of blue. The interior is set to the traditional black.

Back in the day, when fractals and personal computers were new, most color graphic cards had a 256 color table. Each pixel is assigned a color number from 0 to 255 in memory, which is used to look up a color in the table. 16.8 million total colors were possible, but only 256 could be displayed at any one time. That graphics design worked out well for fractal coloring which is basically paint-by-numbers. The original DOS fractal program, Fractint, had a feature that would rapidly change the color table in the graphics card which created a trippy psychedelic effect on the fractal.

Now (and for the last 20 years) computer monitors are capable of displaying all 16.8 million rgb colors.

The palette used in this picture is actually a mathematical formula that takes a (continuous) real number and directly generates a color in the 16.8 million color space.

Even if you define a palette as a list of discrete colors, then by using interpolation it is possible to generate a smooth transition between any two colors in the list. It makes sense to ask for color number 3.2, which would be a blend of 80% color 3, and 20% color 4.

So palettes are, or can easily be made into continuous functions that convert real numbers to colors. The discrete colors in this picture are due to the discrete nature of integer numbers, the escape count, and not due to any limitation in the color palette.

When palettes are defined as continuous functions, it is possible to scale palettes to speed up or slow down color transitions. For example instead of using color(x), one could use color(a*x) where a is a scale factor. The only difference between today’s picture and yesterday’s is a color scale factor of 1/3.

And now, a special addendum for those suffering with technical pedantry syndrome. Yes, 16777216 different colors is still a discrete set of colors. And yes if you look really hard you can see the difference between red #A00000 and red #A10000 which differs in red intensity by 1/256 of the full gamut. But for our purposes, our displays show a continuous range of colors.

## Smooth 1D Colors #3

Today’s image replaces the black and white bands with different colors. Other than the colors, this is the same as yesterday’s R=10 image.

You probably would have chosen different colors. Perhaps opposite or adjacent colors from a color wheel. But it is still trying to find an interesting way to arrange colors in concentric, warped circles.

The focus should be the Mandelbrot set in the middle, not the surrounding color bands. OK, a mathematician may be interested in the equipotential line. But for the rest of us, it is a distraction.

The palette used here is actually my favorite palette, I will use it for the rest of the pictures in this series.

## Smooth 1D Colors #2

In the previous image, the escape threshold was set as tight as possible (R=2.0). Notice how all of the black and white bands meet at the left most tip of the mandelbrot set. This image has a larger threshold, it uses R=10.0. Now there is always a gap between the bands.

Not that we are any closer to smooth coloring. This is just another example of non-continuous colorings.

(Introspective diversion: A normal blogger would combine these multiple posts into a single article. I am trying to get into the habit of making daily posts. Trying to write a large post a day will result in immediate failure. The article never feels complete, and often never gets posted. Whereas, adding one small increment to the story each day is possible, and feels like success. I can find the motivation to add one more picture to the story each day.)
